SRP™ Single Timber Nogs

Timber nogs using untreated timber for mounting taps and other features such as kitchen/bathroom accessories are best positioned using two SRP™ Nog brackets.

Place the untreated timber nogs between the nog brackets and fix securely. Ensure dissimilar metals are isolated and pipes are grommetted through the studs. See FIGURE 15 for timer nog details.

NOTE: Only untreated timber Nogs shall be used in direct contact with any galvanized SRP™ products. If it is unavoidable to use treated timber a separation barrier between the galvanized SRP™ product and the treated timber shall be used.

Single SRP™ Nogs constructed from ex SRP™ Tracks can also be used [see FIGURE 14, option A, B and C for details].
