1. [TABLE 5] can only be used for areas outside of the Lee Zone [see Figure 4] [i.e. Ml=1.0].
2. [TABLE 5] can only be used for areas outside of the Local Topographic Zone [see FIGURE 5] [i.e. Mt=1.0].
3. [TABLE 5] does not take the shielding reduction effect of surrounding buildings into consideration.
4. Height is limited to 20m maximum, measured from the ground level [see FIGURE 6].
The use of these tables, [TABLE 3, TABLE 4, TABLE 5 AND TABLES 6.1 – 6.5] is the responsibility of the specifier, and we strongly recommend a structural engineer to review the entire design, including the site specific Wind Speed and the selection of the Steel SRP™ Studs prior to placing an order.
Download Zone Tables See SRP™ Stud Height Tables
